Product Details:
Payment & Shipping Terms:
|
| Core Components: | Engine | Outward Dimension (Length, Width, Height)mm: | 9920×2500×3990 |
|---|---|---|---|
| Tire Number: | 12 | Horsepower: | 371hp |
| Front Axle: | HF9 | Tyres: | 1200R20, 10+1tyres |
| Water Tank: | Volume 300L | Cabin: | HW76, One Sleeper With Air-conditioner. |
| Agitating Capacity: | 8 Cubic Meters | ||
| High Light: | 273KW Concrete Mixing Transport Trucks Used,Concrete Mixing Transport Trucks Used HW76,Used HW76 Cement Mixer Vehicle |
||
8*4 Cement Mixer Truck 8*4 Sinotruk Howo 8*4 Concrete Cement Mixer Truck
Used Concrete Mixer Truck Of Product Description:
Description
A concrete mixer truck (often colloquially called a cement mixer) is a device that homogeneously combines cement, aggregate such as sand or gravel, and water to form concrete. A typical concrete mixer uses a revolving drum to mix the components.
Application
Concrete mixer truck is made to mix concrete and transport it to the construction site. They can be charged with dry materials and water, with the mixing occurring during transport. They also be loaded from a " central mix" plant; with this process the material has already been mixed prior to loading.
parameter:
| Overall Dimensions | 10900x2500x3950mm(L*W*H) |
||
Tare Weight |
17000kg |
Payload |
40000kg |
Front Overhang |
1500mm |
Rear Overhang |
2880mm |
Wheelbase |
1800+3625+1350mm | Track (F/R) |
2022mm/1830mm |
CHASSIS |
|||
Chassis Brand |
SINOTRUK HOWO |
||
Chassis Model |
driving type 8x4 |
||
Cab |
HW76, left hand drive, air-conditioner, one sleeper |
||
Engine |
SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L |
||
Transmission |
HW19710, No. of speeds: 10 forward 2 reverse |
||
Steering |
German ZF8098, turning system pressure 18MPa |
||
Rear Axle |
HC16 axle, rated load 2x13ton, ratio 5.73 |
||
Wheels and tires |
Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel |
||
Brakes |
Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake |
||
Used Concrete Mixer Truck Of Details:
The advantage of small concrete truck for sale:
1.Low energy consumption and environmental protection.
2.The hydraulic system has the feature of lower energy consumption.
3.Simple quick-change construction can meet multipurpose operation of users.
4.The integrated multi-functional control handle makes operation simple.
Our Service:
High quality first based on our products
We are a professional truck and trailer supplier, and we have many kinds of trucks and trailers for your reference and choices.
Thoughtful and meticulous one-on-one service
We have professional sales who can answer your questions and meet your requirements according to your inquiry. Besides, our professional senior engineers can design and produce the product according to your requirements.
Customers first and perfect service
We will accurately define, fully understand your needs and try our best to meet your requirements quickly. We also provide all the whole service during pre-sale, in sale and after-sale.
Why Choose Us ?
1.Q: What kind of payment do you accept?
A: We accept T/T and L/C; Others payment is negotiable.
2.Q: What's your minimum order quantity?
A: One unit
3.Q: What's your delivery time?
A: 10-20 days after received the deposit.
4.Q: What's warranty time?
A: 12 months or 30,000 km from the date of shipment whichever comes first
5.Q: What's your after-sale service?
A: We provide technical support for our trucks and whole life parts supply
