| Size: | 12500*2500*1550mm | Function: | Transport 20ft 40ft Container |
|---|---|---|---|
| King Pin: | 90#/50# | Tire: | 12R22.5 |
| Material: | Steel | Axle: | 13 Ton Fuwa Brand |
| Curb Quality: | 67 Tons | Load: | 60 Tons |
| Bottom Plate: | Q235 | Circuit Socket: | 7-hole Socket |
| High Light: | 12500mm Flatbed Truck Container,Flatbed Truck Container Q345,Q345 40ft Flat Bed Trailer |
||
Shipping 40 Feet Container Transport Flat Bed Trailer 3 axle Flatbed Semi Trailer Price
New flat bed container trailer 3 axles 4 axles 40ft flatbed tractor trailer
We have been specialized in Truck and Trailer export for 17 years. So we have
rich experience in solving any problems you may have. We have our own
semi-trailer factory and all sales and service team are professional. All kinds
of truck model are available,Just tell us what you need and we will provide
a professional solution for you.
Product introduction
1) Reinforced main beam and side beam to ensure high loading.
2) Adopting China made best brand FUWA axle, Triangle tyres
3) 12 pcs container lock to transport 1 x40ft container or 2 x 20ft container
parameter:
| product name | 40-foot flat container transport truck | ||
| Transport medium | Bulk cargo | ||
| Dimensions | 12500*2500*1560mm | ||
| Self-respect | About 7 tons | ||
| Warranty/Certificate | 12 months | ||
| Production cycle | 15 days | ||
| Curb quality | 67 tons | ||
| Load | 60 tons | ||
| Specification | |||
| Dimensions | 12500*2500*1560mm | ||
| Tow pin height | 1300mm | ||
| Wheelbase | 1310mm | ||
| Wheel base | 1840mm | ||
| Frame body configuration | |||
| Item | Material | Specification | |
| Beam | Q345 | "The height is 500mm, the upper wing plate is 14mm, the lower wing plate is 16mm, and the vertical plate is 8mm; " |
|
| beam | Q345 channel steel | 100mm channel steel | |
| Edge beam | Q345 channel steel | 160mm channel steel | |
| Bottom plate | Q235 | 3mm | |
| Accessories | |||
| Suspension | 3-axis heavy machinery suspension | Leaf spring | 6 racks-90*13*10 |
| Axle specifications/brand | 13T/Fuhua | Number of axles | 3 pieces |
| Tire specification/brand | 12R22.5 | Number of tires | 12 Article |
| Steel ring specification/brand | 9.0-22.5 | Number of steel rims | 12 |
| Outrigger specifications/brand | 28T/Yahua | Traction pin specifications | 50# or 90# interchangeable |
| Brake system | |||
| Brake valve brand | WABCO | Brake chamber specifications/quantity | T30/30-6 only |
| Brake system | Emergency brake system, air brake, dual air pipelines, 6 T30/30 brake air chambers, two 40L air storage tanks | ||
| Electrical circuit system | |||
| Circuit socket | 7-hole socket | Voltage | 24V |
| Lamps | LED lights | Two rear tail lights (including two steering lights, two brake lights, two constant lights), 8 side lights, and two rear triangle reflectors; | |
| Appendix | |||
| 1 tool box | tool:Axle wrench, rocker | ||
| 1 spare tire rack | Water tank | ||
| Lock hands | 8 | ||
Features:
1. Multi functional design,ISO containers,timbers,bulk cargo,bagged cement or grain,animals
transportation
2. Side wall removable,one driver can easily handle it
3. Main beam warranty 2 years
4. World wide semi trailer parts brand like BPW,WABCO,JOST,brand
Why Choose Us
1. LISHIXINTrailer Based on the customer's country roads situation, transport goods and loading
weight requirment,provide semi-trailer solution.
2.LISHIXINhave Experienced sales and engineer support every requirment.
3. Customer's design is available for certain products(OEM);
4. Spare parts for all types of semi-trailer with discount price.
5. LISHIIXN have BV SGS CCC ISO WMI Certificate of conformity for the semi-trailer.
6. English operation Manual.
7. LISHIXIN offer free spare parts for every customer, like speeders,spanner etc.
Product display:
details:
factory:
certification
FAQ:
1.Q: What kind of payment do you accept?
A: We accept T/T and L/C; Others payment is negotiable.
2.Q: What's your minimum order quantity?
A: One unit
3.Q: What's your delivery time?
A: 10-20 days after received the deposit.
4.Q: What's warranty time?
A: 12 months or 30,000 km from the date of shipment whichever comes first
5.Q: What's your after-sale service?
A: We provide technical support for our trucks and whole life parts supply
