Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | China | Brand Name: | LSXC |
|---|---|---|---|
| Payload: | 45T | Type: | Semi-trailer |
| Tire: | 12R22.5 | Twist Lock: | 8 Pcs |
| Cross Member: | 10# Channel Steel(Q235) | Floor: | 3mm Flat Plate |
| High Light: | Flatbed Tractor Trailer 20Ft,37 Ton Flatbed Tractor Trailer,20Ft Container Semi Trailer |
||
Dimension:L*W*H |
12392×2495×1540(mm) |
| Kingpin setting | 800(mm) |
| Kingpin plate height | 1203(mm) |
| Axle Space | 7400mm+1310mm+1310mm |
| Tare weight | 7500kg |
| Payload | 60000kg |
| G.V.W.R | 67500kg |
| Lanidng Gear | Two speed manual operation type |
| Kingpin | 2" OR 3.5" welded type |
| Brake system | Dual line pneumatic brake system |
| ABS | YES |
| Brake Chamber | Type 30/30 spring brake system on all axles |
| Suspension | Tandem type |
| Axle | CIMC/FUWA / BPW axle, 13 ton capacity/set,3PCS |
| Tire | 12R22.5, 13PCS |
| Rim | 9.0-22.5, 13PCS |
| Floor | 3mm checked plate |
| Twist Lock | 12 sets |
| Main Beam | 500/14/6/16 |
| Side Beam | 16# channel steel |
| Cross Beam | Square tube |
| Tool Box | 1 pcs |
| Spare Tire Carrier | 2 units |
| Paint | As customer's request |
Flatbed Truck Trailer Of Design Drawing:
Flatbed Truck Trailer Of Advantages:
1. Extensive usage Fast and efficient. Mainly used for the middle&long-distance transport of the medium&heavy-duty and bulk goods, widely used for variety of the cargoes.
2. The whole vehicle adopts the advanced computer-aided design software to optimize the design,make the Frame reasonable offload&scientific design by FEA( Finite Element Analysis) according to requirement of the vehicle carrying quality.
3. Axles, tires and other supporting parts are all well-known products purchased from domestic and foreign manufacturers.
4. The product quality and reliable, widely used, has become the vehicle of choice for long-distance freight vehicles. The quality of this product is reliable,extensive usage, has become the preferred models of middle&long-distance freight vehicles.
FAQ:
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok, but we need take apart the truck and you should reinstall in your country.
Q: How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q: I want to be your agent in my country, is that ok?
A: It’s ok, if your quantity is big, we will consider. For the first time 50 units is ok.
Q: How about your company's service, especially after-sale service?
A: we can satisfy your demand within 3-7 days. We always do our best to solve all the problems and put our customer's interests in the first place.
Q: What is your payment terms?
A: You can choose to the 30% prepaid and 70% paid before delivery or you can choose the LC 100% at sight.
Q: What is your lead time?
A: Usually it is 30-50 days after deposit received.
