Product Details:
Payment & Shipping Terms:
|
| Length (feet): | 20 Feet | External Dimensions(l X W X H)(mm): | 6.1*2.44*2.59 M |
|---|---|---|---|
| Machinery Test Report: | Provided | Warranty: | 1 Year |
| Shape: | Cylinder | MOQ: | 1 Unit |
| Usage: | Transportaion | Design Pressure: | 2.2Mpa |
| High Light: | BV LNG ISO Container,LNG ISO Container 24500L,24500L Oxygen ISO Tank |
||
The size of the tank container could be 20/30/40 feet. The volumes of the tank container are mainly 20~ 55cbm.
The basic equipment includes side outlet, double sides loading and unloading, double pumps box, double tool box, safety valve, temperature meter, pressure meter, emergency shut valve, fire extinguisher, static electricity protection ground tape, etc.
For the safe usage of the LPG products, we conduct several tests for the LPG tanks such as welding line density test, thermal treatment, hydra press measurement, ray nondestructive test, etc.
|
Product Name
|
T50 gas tank container
|
|
Type
|
Gas Tank Container
|
|
Length (feet)
|
20'
|
|
Capacity
|
24500L
|
|
External Dimensions(l x W x H)(mm)
|
L*W*H 6058x2438x2591mm
|
|
Place of Origin
|
Henan, China
|
|
Brand Name
|
JSX
|
|
Material
|
Steel Q 345R
|
|
Contents
|
LPG/Propane
|
|
Tank Size
|
5913*2425(mm)
|
|
Gross Weight
|
34,000kg
|
|
Tare Weight
|
8040kg
|
|
Design temperature
|
-40 to +55 ℃
|
|
Design pressure
|
2.2MPa
|
|
Tank type code
|
22T8
|
|
Dangerous grade
|
2.1
|
|
Allowable Max Stacking
|
192000kgs
|
T50 ISO Tank Container Of Product details:
FAQ:
Q: What is the MOQ?
A: One unit is OK, please contact for details.
Q: Delivery time?
A: Generally 90 to 120 days, sometimes we have stock. Please contact for details.
Q: What certification do you have?
A: We are authorized by CCS, LR, BV.
Q: What documents do you offer?
A: We offer product quality certification issued by the manufacture, tank drawing, GA drawing, operation instructions and calculation sheet etc for each tank, ceritificate of shipping, such as LR, CCS, BV inspection.
Q: How about the warranty rules
A: Quality warranty period for the tank containers is 12 months from the date of delivery. Vacuum warranty period is three years (including the problems caused by the tank, the vacuum valves, and vacuum gauge tube, but not including artificial damage). If it is The supplier has a charge of maintaining tank containers for lifelong beyond the warranty period, the expenses shall be borne by the buyer (after-sales service in If only the quality problems are caused by the buyer operating tank containers in wrong way ( Including not according to the product specification, and requires of the contract, etc.) or other artificial damages, the problems are not in the warranty scope and Free "3 packets" service, the buyer shall pay for the corresponding costs of maintenan Ce.
Q: Specific technical service issues for other classes.
A: Please contact us, we will provide professional and detailed answers.
