| External Dimensions(l X W X H)(mm): | 6058* 2438* 2591 | Internal Dimensions(l X W X H)(mm): | 5898* 2352* 2393 |
|---|---|---|---|
| Operating Temperature: | -40 To 50℃ | Warranty: | 1 Year |
| Capacity: | 25CBM For This ISO Tank, 26000L | MOQ: | 1 Unit |
| Color: | As Per Your Request | M.G.W: | 34000KG |
| High Light: | Portable LR T50 ISO Tank Container,7500kg T50 ISO Tank Container 26000L,26000L Transport LPG ISO Containers |
||
The stainless steel storage tanks above ground suitable for field as edible oil, juice, beverage, medicine chemical or bio-engineering project,etc.
We manufacture tanks for the petroleum, chemical, and water storage . Our product includes carbon steel, stainless steel, and fiberglass storage oil tanks. We offer a complete range of above ground oil tanks including: gasoline and diesel tank systems, potable water tanks, and a variety of customize oil storage tanks for your specific requirement.
| Type | 20 ISO frame, UN portable tank, T50 |
| Vessel | ASME VIII Div 1& IMDG etc. |
| Shell Material |
Corten Stel- EN10028/ SA-299 Shell- 16.4mm minimum Head- 15.2mm minimum |
| Sunshield | 2mm marine grade aluminium |
| Frame dimensions | 20( L) × 8( W) × 86( H) |
| Tare weight(approx) | 7500kg |
| MGW | 34000kg |
| Working pressure | 22.8bar |
| Test pressure | 28.6bar |
| Approvals | Lloyds or BV Construction Certificate, IMDG, CFR49, ADR/ RID, AAR 600, CSC, TC, TIR, ISO, UIC, US/ UK, DOT |
| Baffles | Provision only |
| Manhole Cover | Dome end-dished to allow fitting of level gauge |
| Relief Valve | 1×3" with provision for bursting disc and manometer |
| Valve Cabinet | Rear end of tank with aluminum lockable hinged door cabinet holds all valves, pressure gauge and themometer |
T50 ISO Tank Container Of Product details:
1. Reply your inquiry in 12 working hours;
2. Experienced staffs answer all your questions;
3. Customer’s design is available for certain products( OEM);
4. Spare parts for all types of engine machinery with reasonable price;
5. Different kinds of semi trailer can be provided with competitive price.
FAQ:
Q: What kinds of tank containers could you provide?
A: 20ft ISO tank container, like standard liquid tanks, electrical heating tanks, reefer tanks, food grade tanks, baffle tanks, swap tanks, gas tanks, H2O2 tanks, AHF tanks, bitumen tanks, different types of lining tanks, etc, and 10ft tanks, offshore tanks, IBC/SBC ,etc.
Q: Do you have the certificates to meet us the transportation ways of the Land Truck, Sea Boat and Railway?
A: Yeah,of course, but the price will be very different by different transportation ways; So kindly please let me know your exact transportation ways before the quoting; And also the certificates will be ready after the tank container passed all kinds of the testing &inspection.
Q: Can I have the drawings of this ISO storage tank containers?
A: Yeah, the existing simple similar drawings of the tank container for your reference only for the beginning, will make the more precise drawings after getting the down payment, and will send this drawing to you for your confirmation before production.
Q: How can I pay the money without risk?
A: You can pay the money to us via Alibaba Trade Assurance, then the alibaba can guarantee your money safe and the delivery on time.
Q: Do you provide OEM Service?
A: Yes, we have a first-class team and could design as per your requirement.
Q: What if my question that wasn’t answered in the FAQ?
A: Contact me or choose the sales to consult directly. We're always happy to help!
