Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | China | Brand Name: | LSXC |
|---|---|---|---|
| Payload: | 45T | Type: | Semi-trailer |
| Tire: | 12R22.5 | Twist Lock: | 8 Pcs |
| Cross Member: | 10# Channel Steel(Q235) | Floor: | 3mm Flat Plate |
| High Light: | Red Q235 Flatbed Truck Trailer,Red 600mm Flatbed Truck Trailer 30T,30T Triple Axle Flatbed Trailer 20ft |
||
| Tare weight | About 6000kg |
| Size | 12500mm×2500mm×1600mm |
| Payload | 45T |
| Main beam | Top flange 14mm,width140mm;Middle Flange 8mm height 500mm; bottom flange16mm,width 140mm |
| Side beam | 16# channel steel(Q235) |
| Cross member | 10# channel steel(Q235) |
| Floor | 3mm Flat Plate |
| Axle | 3 axle 13T ( Original FUWA brand ) |
| Landing gear | Two-speed, manual operating,heavy duty landing gear 28T |
| Suspension | Mechanical suspension |
| Leaf spring | Leaf spring 6sets , 10pcs,90×13 mm |
| Tire | 12R22.5 , 12pcs |
| Wheel rim | 9.0-22.5 , 12pcs |
| Kingpin | 3.5” bolt-in king pin |
| Twist lock | 8 pcs |
| Braking system | WABCO RE6 relay valve ; T30/30 spring brake chamber;40L air tanks |
| Lights | LED 8 side lights and 2 rear lights 2 width lamp |
| Painting | Complete chassis sand blasting to clean rust , 1coat of anticorrosive prime,2coats of final paint |
| Accessories | One tool box;one spare tire carrier;one crank; one shaft head wrench;four side light;two rear light |
Flatbed Truck Trailer Of Design Drawing:
Flatbed Truck Trailer Of Advantages:
1. Extensive usage Fast and efficient. Mainly used for the middle&long-distance transport of the medium&heavy-duty and bulk goods, widely used for variety of the cargoes.
2. The whole vehicle adopts the advanced computer-aided design software to optimize the design,make the Frame reasonable offload&scientific design by FEA( Finite Element Analysis) according to requirement of the vehicle carrying quality.
3. Axles, tires and other supporting parts are all well-known products purchased from domestic and foreign manufacturers.
4. The product quality and reliable, widely used, has become the vehicle of choice for long-distance freight vehicles. The quality of this product is reliable,extensive usage, has become the preferred models of middle&long-distance freight vehicles.
FAQ:
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok, but we need take apart the truck and you should reinstall in your country.
Q: How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q: I want to be your agent in my country, is that ok?
A: It’s ok, if your quantity is big, we will consider. For the first time 50 units is ok.
Q: How about your company's service, especially after-sale service?
A: we can satisfy your demand within 3-7 days. We always do our best to solve all the problems and put our customer's interests in the first place.
Q: What is your payment terms?
A: You can choose to the 30% prepaid and 70% paid before delivery or you can choose the LC 100% at sight.
Q: What is your lead time?
A: Usually it is 30-50 days after deposit received.
