| Axle: | 2 Axle Of Fuwa/BPW/other Axle | Kingpin: | JOST Brand 2" Bolt-in King Pin |
|---|---|---|---|
| Weight: | 5000kg | Suspension: | Mechanical Suspension Or Air Suspension |
| Material: | Steel | Certificate: | CE |
| High Light: | 5000kg Sliding Skeletal Trailer,Sliding Skeletal Trailer T700,T700 2 Axle Flatbed Trailer |
||
Super cost-effective 2-axle yellow customizable skeleton semi-trailer hot sale
20ft container skeleton truck semi trailer is using to transport 20gp containers, the frame is heavy duty and extra durability designed l beam; opting for high tensile steel with T700, welded by automatic submerged-Arc processes. guarantee the quality and stability.
parameter:
|
Specifications
|
|
|
Dimension
|
12.38m×2.48m×1.55m (Outside)
|
|
Payload
|
50T
|
|
Tare weight
|
About 6.5T
|
|
Twist lock
|
12 units
|
|
Chassis
|
|
|
Main beam
|
Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes.
|
|
Frame Beam
|
Top Flange 14mm,width 140mm; Middle Flange 8mm; Bottom Flange 16mm,width 140mm, main beam height 500mm
|
|
Axle
|
3 axles, 13Ton Fuwa brand 16ton brake pads
|
|
Landing Gear
|
28T lifting capacity with two speed
|
|
King Pin
|
2.00 or 3.5 inch bolt-in king pin
|
|
Suspension
|
Mechanical suspension reinforced type
|
|
Leaf Spring
|
90mm(W)*13mm(T)*10 Layer
|
|
Pneumatic Braking System
|
Dual line pneumatic brake system,T30 air chamber ,40L air tanks, Emergency relay valve
|
|
Rim
|
9.0-20*12 pcs
|
|
Tire
|
12R22.5*12 pcs
|
|
Accessories
|
One standard tool box
|
|
Spare tire rack
|
One
|
|
Electrical system
|
24 volt electrical system.7 pin electrical connector. Parking stop, reverse, number plate and indicator lights. rear lights
conform to European standard, rear front and side reflectors |
|
Painting
|
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
|
Product display:
factory:
We have a skilled and experienced R&D team and concentrate on the requirements of our customers. As an experienced manufacturer,we offer a complete product range. For wire harness cutting, stripping, crimping and the various machine series as well as the customized solutions are characterized by innovative and well thought-out ideas, and are therefore optimally tuned to the needs of the customer.Our products are exported to many countries in Africa, Southeast Asia and South America, such as Ghana Philippines Zimbabwe Boswana Nigeria Senegal.Customers are also very satisfied with our products and services.We have ability to solve the problems you may encounter.
FAQ:
1.What's your advantage?
A: Honest business with competitive price and professional service on export process.
2. How I believe you?
A : We consider honest as the life of our company, we can tell you the contact information of our some other clients for you to check our credit. Besides, there is trade assurance from Alibaba, your order and money will be well guaranteed.
3.Can you give warranty of your products?
A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.
4.Where are you? Can I visit you?
A: Sure,welcome to you visit our factory at any time.
5.How about the delivery time?
A: Within 15-35 days after we confirm you requirement.
6.what kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
