Product Details:
Payment & Shipping Terms:
|
| Transmission Model: | HW19710 | Emission Standard: | Euro 2/3/4/5 |
|---|---|---|---|
| Drive Wheel: | 6X4 | Tire Number: | 10+1 |
| Horsepower: | 371/375/420hp | Cab: | HW76 |
| Engine Model: | WD615.47 | Tyre: | 1200R20 |
| High Light: | 375Hp 6x4 Tractor Head,30t 6x4 Tractor Head 1200R20,1200R20 Sinotruk Tractor Head |
||
6x4 New Sinotruk Howo Truck Tractor Head 371Hp 375Hp 420Hp diesel engine 10 Tires
Truck Tractor Head Of Product description:
It’s suitable for towing all kinds semi trailer which is used in Logistics business, construction site and Mining area.
This model is the proven product of SINOTRUK, which features reliable structure, great loading capacity, excellent power from 336-420HP, reliable performance. This model can meet the requirements of different road conditions. This model can satisfy your need of long distance highway transportation.
The fifth version of the highway transport is equipped with iron reinforced frame, Iron shell transmission and two-stage reduction drive axle which can loaded 16 ton, single-stage reduction drive axle, which can loaded 16 ton is optional, mainly used for comprehensive road conditions and overloading of the transport conditions.
Truck Tractor Head Of Product parameters:
| Dimension(Lx W xH)(unloaded)(mm) | 6800×2496×3125 | |||
| Approaching angle/Departure angle(°) | 16/70 | |||
| Overhang(front/rear) (mm) | 1500/725 | |||
| Wheel base (mm) | 3225+1350 | |||
| Max speed(km/h) | 101 | |||
| Cub weight(kg) | 8800 | |||
| Engine(Steyr technology, made in China) | Model | WD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | ||
| Fuel type | Diesel | |||
| Power, max(kw/rpm) | 336HP | |||
| Emission | EUROII | |||
| Fuel tanker capacity(L) | 400L aluminum oil tank | |||
| Transmission | Model | HW19710, 10 speeds forward and 2 reverse | ||
| Brake system | Service brake | Dual circuit compressed air brake | ||
| Parking brake | spring energy, compressed air operating on rear wheels | |||
| Steering system | Model | ZF8118 | ||
| Front axle | HF9 | |||
| Rear axle | HC16 | |||
| Tire | 12.00R20 | |||
| Electrical system | Battery | 2X12V/165Ah | ||
| Alternator | 28V-1500kw | |||
| Starter | 7.5Kw/24V | |||
| Cab | HOWO 76 New face cab(one bed,with air conditioner), all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. | |||
