Product Details:
Payment & Shipping Terms:
|
| Material: | Carbon Steel | Side Fence: | 600mm-3000mm |
|---|---|---|---|
| Platform: | Checked Plate 3mm | Condition: | New |
| Axle Number: | 3 Axles | Twist Locks: | Optional |
| Main Beam: | Heavy Duty H Beam | Kingpin 3.5'': | 90# JOST Bolted Type |
| High Light: | 600mm Animal Transport Trailer,Animal Transport Trailer 12R22.5,12R22.5 Triple Axle Semi Trailer |
||
1. The length can be from 10meters to 15meters.Most customers choose 40ft length.
2. Side board height can be from 600mm-3000mm.
3. Axles number can be 1,2,3 or 4 axles for transporting different weight cargo.
4. The material can be high strength Mn carbon steel or aluminum material.
5. Flat deck can be straight beam or step deck type.
6. The trailer main beam can be telescopic extension to realize the length extendable.
7. Can be with container twist lock to connect with the container.
8. Suspension can be normal leaf springs suspension ,air suspension or bogie suspension.
|
Item
|
specifications
|
Remark
|
|
Material
|
Carbon steel
|
Aluminum optional
|
|
Main beam
|
Heavy duty H beam
|
beam extendable optional
|
|
Axles
|
2/3/4 * 13ton capacity
|
OCT,FUWA,BPW or other Brand
|
|
Suspension
|
Mechanical suspension
|
Air /bogie suspension optional
|
|
Leaf spring
|
Leaf spring
|
Air bag lifting optional
|
|
Tire
|
12R22.5 ,11R22.5, 315/80R22.5, 385/65R22.5
|
Size and brand optional
|
|
Rim
|
9.00-22.5,8.25-22.5,11.75-22.5
|
Other size optional
|
|
King pin
|
2’’/3.5’’ bolt type,SAE standard
|
Welding on type optional
|
|
Landing gear
|
28 Ton two speed
|
JOST or equivalent brand
|
|
Platform
|
Checked plate 3mm
|
Other thickness optional
|
|
Side beam
|
Channel beam 16mm
|
|
|
Side fence
|
600mm-3000mm
|
|
|
Twist locks
|
optional
|
|
|
Braking system
|
Dual line brake system,Double air chamber ,brake valve,40L air tanks ;ABS optional
|
|
|
Electrical
|
LED light , 7 ways ,24V
|
|
|
Painting
|
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
|
|
|
Accessory
|
Tool box,oil tank,spraying system optional
|
|
Stake Semi Trailer Of Details:
Our Advantages:
Two water cycle purification and dust- free coating production lines, effectively solving the primer and topcoat second pollution, the car body adopts two-component epoxy zinc-rich paint, anti-corrosion, anti-scratch.
Added molybdenum alloy and vanadium alloy to increase the strength, toughness and low-temperature impact resistance of the beam.
FAQ:
Q: Are you a manufacturer?
A: Yes, we are a manufacturer. We have passed ISO and CE certificate and our products have been exported to over 20 countries.
Q: Can you produce customizable machines?
A: Yes, we can provide customizable machines according to your requirements. We have 8 senior engineers and can design and supply
higher configuration.
Q: What about your products quality ?
A: Quality is our culture! ”Our factory has advanced production technology and management term.
Q: Can i have samples of this type of flatbed semi trailer to test the quality ?
A: Yes, you can buy any samples to test the quality,our MOQ is 1 unit.
Q: What others we can do ?
A: According to your order, we will provide the best price and quality trucks and trailers.
Q: How to guarantee customers get the goods smoothly after they pay ?
A: Don’t worry, dear. we joined the trade assurance. you can place the order by trade
Q: What's the delivery time ?
A: The delivery time is within 15 working days after receiving your advance payment.
