| Dimension: | 12500*2500*1550mm | Twist Lock: | 12/14 Set ISO Standard |
|---|---|---|---|
| Lights: | 12v/24v LED Waterproof | Axle: | 2/3/4 Axles BPW/FUWA/PDME |
| Chamber: | 4/6/8 Sets T30/30 | Brake Pipe: | Nylon Wire Pipe |
| Brake Valve: | WABCO | Kingpin: | 2"(50mm)/3.5"(90mm) JOST |
| High Light: | 1550mm Skeleton Chassis,Skeleton Container Semi Trailer 24v,Skeleton Container Semi Trailer 1550mm |
||
1. Skeleton semi-trailer, mainly used in the logistics system of ships, ports, routes, highways, transfer stations, bridges, tunnels, and multimodal transport.
2. It is specially used for the transportation of various containers such as 20. 40. 45. 48. 53 feet.
3. Specialized design, highly matched customer needs(Port skeleton car, dangerous goods skeleton car, logistics skeleton car, refrigerated skeleton car four series)
4. The chassis is solid and the brakes are faster and more stable.
5. Laser cutting machine material, robot welding, electrophoresis spray powder and paint process and other intelligent production equipment, so that products more reliable and durable.
| Dimension | 12500*2500*1550mm |
| Twist Lock | 12/14 set ISO Standard |
| Suspenssion | Mechanical / Air / Bogie |
| Axle | 2/3/4 axles BPW/FUWA/PDME |
| Rim | 8/12/16 pieces 9.0-22.5 Steel/Aluminum |
| Tire | 8/12/16 pieces 12R22.5 |
| Chamber | 4/6/8 sets T30/30 |
| Brake Valve | WABCO |
| Main Beam | "I" Section 500mm hieght Q345/T700 matirial |
| Air Tank | 28L |
| Brake Pipe | Nylon Wire Pipe |
| Support Leg | 28T Lifting JOST/YAHUA |
| Kingpin | 2"(50mm)/3.5"(90mm) JOST |
| Lights | 12v/24v LED Waterproof |
Skeleton Container Semi Trailer Of Packing And Shipping:
Experienced teams choose the most suitable shipping way for different clients among containers, Roro and bulk shipment, balance safety and economic cost.
Skeleton Container Semi Trailer Of Our Advantages:
FAQ:
1. Can it be customized to my needs?
Of course, the sales manager and technical staff will customize the car according to your needs, confirm the plan and details for you, and arrange production after you sign and confirm!
2. How long is the lead time?
Trailer production cycle is 7-25 days, we will reasonably arrange the production time of the factory according to your urgency, and there are some stock available for you to choose.
3. How long is the warranty period?
We will provide spare parts for free within one year, and provide you with vehicle operation and maintenance skills, life-long vehicle consultation, and we promise that you will receive timely feedback and solutions for any suggestions on trailers
4. What is the price of the trailer?
Different configurations and different prices, the sales manager will provide more cost-effective products according to your budget.
5. What payment methods are available?
You can choose T/T, L/T or other feasible payment methods
