Product Details:
Payment & Shipping Terms:
|
| Certification: | ISO9001 | Design Temperature: | -40 ~ +130 ℃ |
|---|---|---|---|
| Design Pressure:: | 0.175Mpa | Warranty: | 1 Year |
| External Dimensions(l X W X H)(mm): | 6058*2438*2891/mm, | Material: | Q235 Carbon Steel |
| Design Approvals: | IMDG, CFR49, ADR/RID, AAR 600, CSC, TC, TIR, ISO UIC, US/UK | Volume: | 52 CBM |
| Curb Weight (kg): | 4300 | Tank Material: | Cartridge Q235 Carbon Steel /5mm, Head Q235 Carbon Steel /5mm |
| High Light: | 52 CBM 40ft Tank Container,Tank Container Transport T1 ISO,40ft Tank Container T1 ISO |
||
Liquid Storage Tank Container Aseptic Storage Tank Food Grade Edible Oil Container for Sale
Introduction to tank container:
The stainless steel storage tanks above ground suitable for field as edible oil, juice, beverage,
medicine chemical or bio-engineering project,etc. We manufacture tanks for the petroleum,
chemical, and water storage . Our product includes carbon steel, stainless steel, and fiberglass
storage oil tanks. We offer a complete range of above ground oil tanks including: gasoline
and diesel tank systems, potable water tanks, and a variety of customize oil storage
tanks for your specific requirement.
parameter:
|
product name
|
Liquid tank container
|
|
Transport medium
|
Fuel
|
|
Production cycle
|
30 days
|
|
Volume
|
52 CBM
|
|
design standards
|
National standard
|
|
Warranty/Certificate
|
Have
|
|
Product parameters (main configuration)
|
|
|
Item
|
Specification
|
|
Tank material
|
Cartridge Q235 carbon steel /5mm, head Q235 carbon steel /5mm
|
|
Beam material
|
Q235B/5mm
|
|
Shape
|
Rectangular
|
|
Curb weight (kg)
|
4300
|
|
Head thickness
|
5mm
|
|
Tank thickness
|
5mm
|
|
Resistance wave plate
|
Q235B/4.75mm
|
|
Blocking board coaming
|
Q235B/3.5mm
|
|
breather valve
|
1 / stainless steel
|
|
Test pressure
|
6.0bar
|
|
Manhole
|
2piece
|
|
Discharge valve
|
2 piece/Stainless steel DN80
|
|
colour
|
According to user requirements
|
|
other
|
Simple ladder, fire extinguisher, etc.
|
|
Surface treatment
|
Acrylic acid and alkali resistant paint, the total thickness of the paint is 150um, the color can be specified
|
1. Stainless steel tank container is suitable for edible oil, fruit juice, beverage, medicine, chemical ISO container tank
industry and other industries.
2. We manufacture tank containers for petroleum, chemical and water transportation. Our products
include carbon
Steel, stainless steel.
3. We provide a full range of oil tanks, including: gasoline and diesel tanks, drinking water tanks and
various customized oil tank containers to meet your specific requirements.
4. We provide T75 and T50 gas tank containers.
Product advantages:
1: We can provide different sizes of tank containers from 20 FT to 40 FT, and can accept
customized any special tank containers.
2. iso tank containers, acid, soda, liquefied petroleum gas and other tank containers. Various
chemicals can be transported and stored
3. Our iso tank containers are mainly exported to Africa, Asia and South America, such as
Nigeria, Ghana, Kenya, Vietnam, Peru, etc. Our tank containers can also be exported all
over the world because our standard tank containers are of international standard.
Product details:
Type of Tank Container
1) According to the physical properties of the medium
Liquid Tank container - a tank for transport of liquid.
Gas Tank container - a tank that is suitable for the transport of gases
powder Tank container- a tank for the transport of grains and powders
2)According to the functional characteristics of the tank
Food-grade tank container - a tank container which can only be loaded with food grade products
Reefer tank container- a tank with the ability to cool the product to be transported
Electric heating tank container - a tank with the ability to heat the product to be transported
Lined tank container- a tank container with rubber or special painting liner.
SWAP Body tank container - a tank container with swap body and have a large volume.
3)UN T Type Code
T1 ISO tank container (for wine and light liquids )
T3 ISO tank container (for bitumen, Chocolate)
T4 ISO tank container (for non-hazardous edible and non-edible oils)
T7 ISO tank container (for non-hazardous edible and non-edible oils and chemicals)
T11 ISO tank container (for non-hazardous chemicals)
T14 ISO tank container (for hazardous chemicals and acids like HCL and zinc chloride)
T22 ISO tank container (for High hazardous chemicals)
T23 ISO tank container (for Organic Peroxides)
T50 ISO tank container (for High pressure liquefied gas,like LPG and ammonia gas)
T75 ISO tank container (for Liquefied gas at low temperature,like LNG, LCO2, LO2, LN2,)
Food Grade ISO 20ft Edible Oil Tank Container for Sale
The ISO Tank Container was developed for the carriage of all types of liquids, but not limited to potable
(food grade) liquids, non-hazardous and hazardous liquids, including corrosives, flammables, toxics,
and explosives. The Tank Container eliminates the risks in transferring liquids from one vessel to
another, and provides an extremely safe, secure, cost effective, and viable mode of transportation.
Certificate
Factory Tour:
FAQ:
Q: Do you accept small quantity order?
A: Yes, 1 pc for food grade tank container
Q: Color & logo can be choose?
A: No problem
Q: What is the design code?
A: ASME
Q: How about the payment?
A: Usually in container line, it is 50% T/T deposit in advance, the blance is paid before shipment.
Q: Is the size customizable?
A: Sure, we can provide 40ft or swamp body food grade tank
Q:Can you produce customized container?
A: Yes,we can manufacture many kinds of special container.
If you need more info. for ISO food grade tank container, pls feel free to contact us.
