Product Details:
Payment & Shipping Terms:
|
| Weight: | 12300(kg) | Overall Size(Frame)/L*W*H/mm: | 12192*2438*2591 |
|---|---|---|---|
| Tank Volume: | 36 Cubic | Tank Material: | Head 304L/8mm, Cylinder 304L/8mm |
| Rated Speed: | 2200rpm | Rotating Speed: | 740r/min |
| Core Components: | PLC, Pressure Vessel, Pump | Beam Material: | Q235/8mm |
| Ultimate Vacuum: | 0.093Mpa | ||
| High Light: | 2200rpm 20 Ft ISO Tank Container,20 Ft ISO Tank Container 36 cub,36 Cub Carbon Steel Container |
||
20 ft. 40 ft. Stainless steel and carbon steel vacuum suction transport tank container from large
factory in China
Liquid storage tank container is widely used in industries for liquid transportation on the road/ rail/ ship
and storage.ISO tank container:
1. Inner layer - made of 6 or 8 mm thick Q235-B steel plate, compared with ordinary 5 mm thick
single-layer tank, the strength is greatly improved;
2.Outer layer - tempered glass fiber thickness of 4.0mm or more, good compressive and seismic
resistance. It has strong corrosion resistance and corrosion resistance.
Unique technology is adopted between the inner and outer layers to make it reach a gap of 0.1-1mm,
so as to eliminate hidden dangers from the root.
Leak detector 24 hours to monitor, to prevent leakage caused by security risks.
parameter:
| product Overview | |||
| product name | 36 cubic sewage suction tank | model | LSXC9400GXW |
| Transport medium | Liquid dirt | Volume | 36 cubic |
| Overall dimensions(mm) | 12192*2438*2591 | Tank size(mm) | 10400*diameter 2100 |
| Weight (kg) | 12300 | Load (kg) | 36000 |
| Production cycle | 30 days | Warranty/Certificate | Have |
| Product parameters (main configuration) | |||
| Item | Specification | Remark | |
| Tank material | 304L/8mm | ||
| Beam material | Q235/8mm | ||
| shape | Round | ||
| Tank volume | 36 cubic | ||
| Tank material | Head 304L/8mm, cylinder 304L/8mm | ||
| Vacuum pump | Water ring vacuum pump | ||
| Ultimate vacuum | 0.093Mpa | ||
| Rotating speed | 740r/min | ||
| Maximum pumping speed | 42 cubic meters/min | ||
| power | 90KW | ||
| caliber | Import: DN150, Export: DN150 | ||
| Water consumption | 100-150L/min | ||
| Total pump weight | 460KG | ||
| Auxiliary engine | WD12.220 | With one-key start | |
| Engine brand | Weichai | ||
| Fuel type | diesel fuel | ||
Liquid storage tank container is widely used in industries for liquid transportation on the road/ rail/ ship
and storage.ISO tank container:
1. Inner layer - made of 6 or 8 mm thick Q235-B steel plate, compared with
ordinary 5 mm thick single-layer tank, the strength is greatly improved;
2.Outer layer - tempered glass fiber thickness of 4.0mm or more, good compressive and seismic resistance.
It has strong corrosion resistance and corrosion resistance.Unique technology is adopted between the inner
and outer layers to make it reach a gap of 0.1-1mm, so as to eliminate hidden dangers from the root. Leak
detector 24 hours to monitor, to prevent leakage caused by security risks.
Product advantages:
1: We can provide different sizes of tank containers from 20 FT to 40 FT, and can accept customized any
special tank containers.
2. iso tank containers, acid, soda, liquefied petroleum gas and other tank containers. Various chemicals can
be transported and stored
3. Our iso tank containers are mainly exported to Africa, Asia and South America, such as Nigeria, Ghana,
Kenya, Vietnam, Peru, etc. Our tank containers can also be exported all over the world because our standard
tank containers are of international standard.
Product details:
1). cutting materials for preparing oil tanks manufacture
2). rolling machines for circling
3). welding and NDT(non-defection test) inspection
4). re-circling after welding
5). outer vessel’s abrasive blasting and anti corrosive painting for outside surface
6). pipe connecting and assembly of inner vessel and outer vessel
7). valves installation
8). perlite filling
9). vacuum-pumping
10). final painting and ready for shipment
Factory Tour:
FAQ:
5.1. Are your container fuel tank brand new?
Yes, all the container we provided are brand new. In fact, we will produce new container after order confirmation.
5.2 Does your container fuel tank meet with international requirement?
All of our tank container will be approval by BV or LR or CCS and meet with below requirement.
ISO 1496/3
UN Transport of Dangerous Goods
UIC International Rail Approval
TIR International Transport Goods under Custom Seal
CSC International Convention for Safe Containers
DOT US Code Federal Regulations CFR49
DOT UK Carriage of Dangerous Goods
CTC Canadian Transport Commission (Rail)
AAR American Association of Railroads
FRA Federal Rail Association USA
BAM G.D.R Domestic Approval
ISO/TC11
5.3 Can you provide Drawings for confirmation?
Yes, we will provide drawing after order confirmed before production
5.4 Do you have Small or Large Volume Tank Container?
Sure, we could do Tank Container form 1000L to 60000L. And could produce offshore Tank as per DNV2.7-1 / EN12079 Standard.
5.5 Do you provide OEM Service?
Yes, we have a first-class team and could design as per your requirement.
